Cards and Readers for Hands Free Multiple Reading Performance

Firmware Summary for CR1A-DS and CR1A-DS1 readers.

Firmware description

Product Order Code

Dual or Inward Twin Operation:

CR1A-DS-D or CR1A-DS1-D

This assumes there are two independent detection zones providing omni-directional information (i.e. no direction sensing) regarding tags entering each zone.

Each detection zone is controlled independently and one output is provided for each zone.

Direction Sensing versions.

Control

CR1A-DS-C or CR1A-DS1-C

Ideal for car park control or any other applications where directional information is required for each tag. System reports tag from the zone it is first seen, this sets a timer running for each tag enabling them to cross through the second detection zone without a report being genreated. Timer can adjusted in 1 second intervals within the unit.

Enhanced Control

CR1A-DS-EC or CR1A-DS1-EC

Ideal for hands free secure door applications. The unit provides two reports for every tag detected passing through the portal/door under control. Last report provides confirmation as to where the tag holder is in relationship to the door. A tag seen passing across the face of the door being monitored would only produce a single report.

Anti-pass-back.

CR1A-DS-APB or CR1A-DS1-APB

Ideal for hands free secure door applications. The unit provides a single report for every tag detected passing through the portal/door under control. A tag seen passing across the face of the door under control would result in two reports being generated, this ensures the last known location for the tag holder is correct.

Tracking

CR1A-DS-T or CR1A-DS1-T

This version of the reader firmware only generates a tag report when a tag is seen moving from one detection zone to another. A tag standing in both detection zones will generate a report every time the aerials are switched.

Enhanced Tracking

CR1A-DS-ET or CR1A-DS1-ET

This version of the reader firmware generates a single report as soon as a tag is seen crossing from one detection zone to another. If the tag leaves the detection zones by the same zone as it first entered a second report is generated to correct its attendance status.

Safety

CR1A-DS-S or CR1A-DS1-S

A single report is generated once the tag has been lost from the detection zone for 2 seconds.

For further assistance in selecting the right version of reader firmware please contact Identec Ltd.

Firmware Summary for CR1A-DS and CR1A-DS1 readers.
Firmware description		Product Order Code
Dual or Inward Twin Operation:		CR1A-DS-D or CR1A-DS1-D
This assumes there are two independent detection zones providing omni-directional information (i.e. no direction sensing) regarding tags entering each zone. Each detection zone is controlled independently and one output is provided for each zone.

Direction Sensing versions.
Control		CR1A-DS-C or CR1A-DS1-C
Ideal for car park control or any other applications where directional information is required for each tag. System reports tag from the zone it is first seen, this sets a timer running for each tag enabling them to cross through the second detection zone without a report being genreated. Timer can adjusted in 1 second intervals within the unit.

Enhanced Control		CR1A-DS-EC or CR1A-DS1-EC
Ideal for hands free secure door applications. The unit provides two reports for every tag detected passing through the portal/door under control. Last report provides confirmation as to where the tag holder is in relationship to the door. A tag seen passing across the face of the door being monitored would only produce a single report.

Anti-pass-back.		CR1A-DS-APB or CR1A-DS1-APB
Ideal for hands free secure door applications. The unit provides a single report for every tag detected passing through the portal/door under control. A tag seen passing across the face of the door under control would result in two reports being generated, this ensures the last known location for the tag holder is correct.

Tracking		CR1A-DS-T or CR1A-DS1-T
This version of the reader firmware only generates a tag report when a tag is seen moving from one detection zone to another. A tag standing in both detection zones will generate a report every time the aerials are switched.

Enhanced Tracking		CR1A-DS-ET or CR1A-DS1-ET
This version of the reader firmware generates a single report as soon as a tag is seen crossing from one detection zone to another. If the tag leaves the detection zones by the same zone as it first entered a second report is generated to correct its attendance status.

Safety		CR1A-DS-S or CR1A-DS1-S
A single report is generated once the tag has been lost from the detection zone for 2 seconds.


For further assistance in selecting the right version of reader firmware please contact Identec Ltd.
