Cards and Readers for Hands Free Multiple Reading Performance

CR1A
Configurable Loop Aerial Reader

300 x 230 x 80 mm

-20 to +60 C

Single piece reader supplied with internal aerial that provides 1.2 metres reading radius. Link selectable external aerial provides opportunity to increase reading range up to 3.0 metres radius from door frame antenna. Unit supplied with three LEDs and buzzer. Normal operation:- Red LED on when power connected flashes once when tag is detected, Amber LED flashes when tag is detected, Green LED controlled externally, buzzer sounds when tag with battery low flag detected. Operates from 12 - 28 volts dc, standard output 26 bit Wiegand.

Numerous options can be provided in the reader firmware. Reporting modes can be changed to report tags leaving the field, continuously while in the field or in and out of the field. LED & buzzer functions can be modified. Performance test tag PTT1, extended/remote LED & buzzer ED1 and tag counter display EDN1 options available.

Convenient Hands Free Access Control, Car Park Control, Asset Tracking, Process Control any Subliminal Identification applications where numerous tags must be faithfully identified simultaneously.

CR1A-MS
Master/Slave Loop Configurable Aerial Reader

300 x 230 x 80 mm

-20 to +60 C

Single piece reader suitable for monitoring two external loop aerials creating a single detection zone, each aerial providing a reading range up to 3.0 metres radius. Unit supplied with three LEDs and buzzer. Normal operation:- Red LED on when power connected flashes once when tag is detected, Amber LED flashes when tag is detected, Green LED controlled externally, buzzer sounds when tag with battery low flag detected. Operates from 12 - 28 volts dc, standard output 26 bit Wiegand.

Numerous options can be provided in the reader firmware. Reporting modes can be changed to report tags leaving the field, continuously while in the field or in and out of the field. LED & buzzer functions can be modified. Performance test tags 2 x PTT1, extended/remote LED & buzzer ED1 and tag counter display EDN1 options available.

Convenient Hands Free Access Control, Car Park Control, Asset Tracking, Process Control any Subliminal Identification applications where numerous tags must be faithfully identified simultaneously.

CR1A-DS(x)
Dual Loop Configurable Aerial Reader

300 x 230 x 80 mm

-20 to +60 C

Single piece reader suitable for monitoring two external loop aerials creating two independent detection zones, each providing a reading range up to 3.0 metres radius. Unit supplied with three LEDs and buzzer. Normal operation:- Red LED on when power connected flashes once when tag is detected, Amber LED flashes when tag is detected, Green LED controlled externally, buzzer sounds when tag with battery low flag detected. Operates from 12 - 28 volts dc, standard output provides two independent 26 bit Wiegand outputs. Firmware determines the functionality of the reader (i.e. Direction sensing or independent loops)

Numerous options can be provided in the reader firmware see detailed description of each option at the end of this document. LED & buzzer functions can be modified. Performance test tags 2 x PTT1, extended/remote LED & buzzer ED1 and tag counter display EDN1 options available. Two RS232 output ports also available.

Safety Registration, Convenient Hands Free Access Control, Car Park Control, Asset Tracking, Process Control any Subliminal Identification applications where numerous tags must be faithfully identified simultaneously.

Readers
Type No.
Basic Description
Features
Options
Applications.

CR1A-DS-MS
Master/Slave Dual Loop Configurable Aerial Reader.

300 x 230 x 120 mm

-20 to +60 C

Single piece reader suitable for monitoring four external loop aerials creating two independent detection zones, each loop aerial provides a reading range up to 3.0 metres radius. Unit supplied with three LEDs and buzzer. Normal operation:- Red LED on when power connected flashes once when tag is detected, Amber LED flashes when tag is detected, Green LED controlled externally, buzzer sounds when tag with battery low flag detected. Operates from 12 - 28 volts dc, standard output provides two independent 26 bit Wiegand outputs.

Numerous options can be provided in the reader firmware see detailed description of each option at the end of this document. LED & buzzer functions can be modified. Performance test tags 4 x PTT1, extended/remote LED & buzzer ED1 and tag counter display EDN1 options available. Two RS232 output ports also available.

Safety Registration, Convenient Hands Free Access Control, Car Park Control, Asset Tracking, Process Control any Subliminal Identification applications where numerous tags must be faithfully identified simultaneously.

CR1A-DS1-S
Split Transmitter and Receiver Loop Aerial Reader

300 x 230 x 80 mm

-20 to +60 C

Single piece reader supplied with two SL4 receiver pods. External loop aerial provides "wake up" for tags up to 3.0 metres radius from a door frame antenna. Receiver pods can be positioned to shape the detection field and also to reduce the effect of electrical interference which might stop a standard CR1 unit from working. Unit supplied with three LEDs and buzzer. Normal operation:- Red LED on when power connected flashes once when tag is detected, Amber LED flashes when tag is detected, Green LED controlled externally, buzzer sounds when tag with battery low flag detected. Operates from 12 - 28 volts dc, standard output 26 bit Wiegand.

Numerous options can be provided in the reader firmware. Reporting modes can be changed to report tags leaving the field, continuously while in the field or in and out of the field. LED & buzzer functions can be modified. Performance test tag PTT1, extended/remote LED & buzzer ED1 and tag counter display EDN1 options available.

Convenient Hands Free Access Control, Car Park Control, Asset Tracking, Process Control any Subliminal Identification applications where numerous tags must be faithfully identified simultaneously.

Readers
Type No.
Basic Description
Features
Options
Applications.

CR1A-DS1(x)
Split Transmitter and Receiver Loop Aerial reader for direction sensing.

300 x230 x 80 mm

-20 to +60 C

Single piece reader supplied with two SL4 receiver pods. External loop aerial provides a "wake up" for tags up to 3.0 metres radius from a door frame antenna. Receiver pods can be positioned to create two distinct detection zones to enable direction sensing. Unit supplied with three LEDs and buzzer normal operation - Red LED on when power connected, Amber LED flashes when tag is detected, Green LED controlled externally, buzzer sounds when tag with battery low flag detected. Operates from 12 - 28 volts dc, standard output provides two independent 26 bit Wiegand outputs. Firmware determines the functionality of the reader (i.e. Direction sensing or independent loops)

Numerous options can be provided in the reader firmware see detailed description of each option at the end of this document. LED & buzzer functions can be modified. Performance test tags 2 x PTT1, extended/remote LED & buzzer ED1 and tag counter display EDN1 options available. Two RS232 output ports also available.

Safety Registration, Convenient Hands Free Access Control, Car Park Control, Asset Tracking, Process Control any Subliminal Identification applications where numerous tags must be faithfully identified simultaneously.
