Cards and Readers for Hands Free Multiple Reading Performance

Readers
Type No.
Basic Description
Features
Options
Applications.

EC1A
Mullion Reader.

116 x 40 x 16 mm

-20 to +60 C

Single piece reader supplied in black ABS, 5 - 18 volt dc operation, screw terminal connection, typical reading range 150 mm. Two LED's, Green controlled externally, Red on when powered and flashes when tag in field.

EC2 variant when output format changed from standard 26 bit Wiegand, or when other options are required. Alternative white housing colour possible, also customised front labels available. Buzzer can be fitted to sound whenever a tag is detected but not sound when a battery low tag has been detected.

High security access control. Tag tester, Hand held reader for asset identification.

ELC1A
Label Reader

210 x 160 x 4.5 mm

-20 to +60 C

Single piece reader supplied in grey ABS, 6 - 18 volt dc operation, screw terminal connection, typical reading range 1M. Two LED's, Green controlled externally, Red on when powered and flashes when tag in field. Unit supplied with surface mounting spacer and two sets of front and back labels. Suitable for mounting directly on wooden door, or direct onto an electrical back box to provide a 4.5 mm profile. Alternatively may be surface mounted on glass or wall to provide a 15 mm profile. Can also mount on a swan neck pipe supplied by others. Suitable for internal or external operation.

ELC2 variant when output format changed from standard 26 bit Wiegand, or when other options are required. Alternatives include paint finished housing, customised label inserts.

Convenient Hands Free Access Control, Car Park Control, Hand held wand for asset monitoring.

Readers
Type No.
Basic Description
Features
Options
Applications.

ELC1A-MS
Master/Slave Label Reader

2x 210 x 160 x 4.5 mm

-20 to +60 C

Two Label readers supplied in grey ABS that operate in tandem, 6 - 18 volt dc operation, screw terminal connection, typical reading range 1M from each reader plate. Master fitted with two LED's - Green controlled externally, Red on when powered and flashes when tag in field. Units supplied with surface mounting spacer and two sets of front and back labels. Suitable for mounting directly on wooden door, or direct onto an electrical back box to provide a 4.5 mm profile. Alternatively may be surface mounted on glass or wall to provide a 15 mm profile. Can also mount on a swan neck pipe supplied by others. Suitable for internal or external operation.

ELC2-MS variant when output format changed from standard 26 bit Wiegand, or when other options are required. Alternatives include paint finished housing, customised label inserts.

Convenient Hands Free Access Control, Car Park Control.

Readers	Type No.	Basic Description	Features	Options	Applications.
	EC1A	Mullion Reader. 116 x 40 x 16 mm -20 to +60 C	Single piece reader supplied in black ABS, 5 - 18 volt dc operation, screw terminal connection, typical reading range 150 mm. Two LED's, Green controlled externally, Red on when powered and flashes when tag in field.	EC2 variant when output format changed from standard 26 bit Wiegand, or when other options are required. Alternative white housing colour possible, also customised front labels available. Buzzer can be fitted to sound whenever a tag is detected but not sound when a battery low tag has been detected.	High security access control. Tag tester, Hand held reader for asset identification.
	ELC1A	Label Reader 210 x 160 x 4.5 mm -20 to +60 C	Single piece reader supplied in grey ABS, 6 - 18 volt dc operation, screw terminal connection, typical reading range 1M. Two LED's, Green controlled externally, Red on when powered and flashes when tag in field. Unit supplied with surface mounting spacer and two sets of front and back labels. Suitable for mounting directly on wooden door, or direct onto an electrical back box to provide a 4.5 mm profile. Alternatively may be surface mounted on glass or wall to provide a 15 mm profile. Can also mount on a swan neck pipe supplied by others. Suitable for internal or external operation.	ELC2 variant when output format changed from standard 26 bit Wiegand, or when other options are required. Alternatives include paint finished housing, customised label inserts.	Convenient Hands Free Access Control, Car Park Control, Hand held wand for asset monitoring.
Readers	Type No.	Basic Description	Features	Options	Applications.
	ELC1A-MS	Master/Slave Label Reader 2x 210 x 160 x 4.5 mm -20 to +60 C	Two Label readers supplied in grey ABS that operate in tandem, 6 - 18 volt dc operation, screw terminal connection, typical reading range 1M from each reader plate. Master fitted with two LED's - Green controlled externally, Red on when powered and flashes when tag in field. Units supplied with surface mounting spacer and two sets of front and back labels. Suitable for mounting directly on wooden door, or direct onto an electrical back box to provide a 4.5 mm profile. Alternatively may be surface mounted on glass or wall to provide a 15 mm profile. Can also mount on a swan neck pipe supplied by others. Suitable for internal or external operation.	ELC2-MS variant when output format changed from standard 26 bit Wiegand, or when other options are required. Alternatives include paint finished housing, customised label inserts.	Convenient Hands Free Access Control, Car Park Control.
